Angled and Curved designs
Prior to accepting orders for design (atypical) trench heaters, the manufacturer must assess the feasibility of the project. Heat outputs cannot be guaranteed, but the manufacturer will carry out a professional heat output estimate on request.
Specifications
| Length | max. 3 000 mm |
| Module depth | 70, 90, 110, 130, 150, 190 mm |
| Design width | 140, 160, 200, 260, 320, 340, 400 mm |
| Casing material | Galvanized steel casing, RAL 9005 black lacquered |
| Frame | Alu U-frame (silver, light and dark bronze elox) nebo lakován dle vzorníku RAL |
| Grille | roll-up, aluminium (silver, light and dark bronze elox), wood, steel and stainless steel nebo lakován dle vzorníku RAL |
Angled design
For all shapes, including curved designs, the following must be specified: angle (α), inner radius (r) or outer radius (R) and the total width (W) corresponding to trench heater widths manufactured. Grilles must be ordered together with design trench heaters.
Curved parts
The minimum inner radius of curved parts must be greater than 2000 mm. When fitting aliminium grilles to curved parts, the slats will be T-profiles set on springs (see picture) and using a U-frame. (Due to construction reasons, F-frames cannot be fitted to curved trench heaters.)
When ordering, please fill in the special product form. Product form is available at Enquiry form for production of specific convector, floor grid ANGLED AND CURVED DESIGNS
 |  |
 |  |
